Kiwi Pi-P1
Quad-core ARM 64-bit, 4*Cortex-A76@2.2GHz + 4*Cortex-A55@1.8GHz
USD $99.00 – $178.99
Fast shipping & 1W+ Sold
Rockchip RK3588S Quad-Core A76+A55 ARM Mali-G610 MC4 , 6.0 TOPs NPU
∞
Sold
7x24 Hours
Technical Support
1 V 1
Service
Product Highlights:
- 8nm process, Quad-core ARM 64-bit, 4*Cortex-A76@2.2GHz + 4*Cortex-A55@1.8GHz
- ARM Mali-G610 MC4 , embedded high performance 2D image acceleration module
- 6.0 TOPs NPU, enable various AI applications
- 8K video codec, 8K@60fps display out
- Linux 5.10 (option:Linux6.10), Android12, Debian11, Ubuntu22.04
Matching package
USD $239.00 – $278.99
Fast shipping & 1W+ Sold
Kiwi Pi-P1
Key features
- 8nm process, Quad-core ARM 64-bit, 4Cortex-A76@2.2GHz + 4Cortex-A55@1.8GHz
- ARM Mali-G610 MC4 , embedded high performance 2D image acceleration module
- 6.0 TOPs NPU, enable various AI applications
- 8K video codec, 8K@60fps display out
- Rich Display Interface, multi-screen display
- Super 32MP ISP with with HDR&3DNR, multi-camera inputs
- Rich high-speed interfaces (PCIe, TYPE-C, SATA, Gigabit ethernet)
- Linux 5.10 (option:Linux6.10), Android12, Debian11, Ubuntu22.04
DETAIL SPEC
| CPU | Rockchip RK3588S, 8nm process Quad-core ARM 64-bit 4*Cortex-A76@2.2GHz + 4*Cortex-A55@1.8GHz |
| GPU | ARM Mali-G610 MC4 OpenGL ES 1.1/2.0/3.1/3.2 OpenCL 1.1/1.2/2.0 Vulkan 1.1/1.2 High performance 2D image acceleration |
| NPU | Triple-core NPU, 6 TOPS Performance Support int4/int8/int16/FP16/BF16/TF32 acceleration Enable various AI applications |
| VPU | Video Decoding: 8K@60fps: H.265/VP9/AVS2 8K@30fps: H.264 AVC/MVC 4K@60fps: AV1 1080P@60fps: MPEG-2/-1/VC-1/VP8 Video Encoding: 8K@30fps: H.265/H.264 |
| DDR | LPDDR4X 8GB (option: 4/16/32GB) 2133MHz, 64-bit |
| Storage | eMMC 64GB (Option:128GB/256GB/512GB) MicroSD (TF) Card Slot |
| USB | 1*Type-C (Full funtion:USB3.1-OTG,DP ALT,PD) 2*USB 3.0 Host 2*USB 2.0 Host |
| Video Output | HDMI2.1（Maximum resolution 8K@60fps) Type-C DP1.4（maximum resolution 8K@30fps) Mipi-DSI 4-Lane（maximum resolution 2560*1600@60fps） |
| Video Iutput | 2 * MIPI-CSI 4Lane |
| Wireless | WiFi 6 (IEEE802.11 a/b/g/n/ac/ax up to 600.4Mbps) BT5.4 2.4Ghz and 5Ghz band channels, 2T2R |
| Ethernet | 1000Mbps RJ45 |
| Audio | 3.5mm headphone jack with stereo audio output and mic input On board mic input |
| Expansion Port | 26Pin header including Power output , I/O,power on/off key,Debugging I/O Pin can be program to UART, PWM, I2C, SPI, CAN, GPIO etc |
| Button | Recovery key Reset key |
| LED | Red/Green LEDs |
| Power Supply | Type-C PD 12V/2A Support QC2.0/PD3.1/BC1.2 and The third party charging protocols |
| Supported OS | Linux 5.10 (option:Linux6.10) Android12, Debian11, Ubuntu22.04 |
| Dimension | 56mm(L) x 85mm(W) |
| Weight | 300Grams |
